• Flask Cure Infrared Refineries
• Heating system for Refineries
• Oil Heating System
• Hot Water Generator and Heat Exchanger
• Heat Exchanger
• Gas Fired Hot Air Generator

We offer a wide range of Industrial Heating Equipments, extensively used in various industrial purposes. They are known for their high conductivity and durability. The heating equipments are made of high quality raw material sourced from very reliable vendors. They are used in malls, corporate houses and government’s offices.

The range includes

Flask Cure Infrared Dryers

A wide range of Flask Cure Infrared Dryers are available which has been manufactured by high quality raw material and sophisticated technology. The dryers are of high quality and high performance. High efficiency, low power consumption and compacts size are the factors which lead to clients appreciating the range off dryers available. They can be customized in accordance with the international standards and client’s specification.

Heating System for Refineries

We offer a wide range of Heating Systems for refineries for quick heating without consuming much energy. They are very easy to install and have a growing demand in the global market. Heating Systems are available in different technical specifications and the same can be customized for any client to suit their individual requirement within a given time frame.

Oil Heating System

We offer a wide range of Oil Heating Systems of high quality standard. The client’s appreciation comes for its high efficiency and durability. It can be customized according to the client’s specification and can be used in large number of applications.

Hot Water Generator and Heat Exchanger

We manufacture Hot Water Generators for a variety of fuels including solid fuels. Heat exchangers are available in various ranges such as Condensers, Vent Condensers, Re-boilers and Sub-coolers depending upon process requirement.

Heat Exchanger

A heat exchanger is a device built for efficient heat transfer from one medium to another. The media may be separated by a solid wall, so that they never mix, or they may be in direct contact. They are widely used in space heating, refrigeration, air conditioning, power plants, chemical plants, petrochemical plants, petroleum refineries, natural gas processing, and sewage treatment. One common example of a heat exchanger is the radiator in a car, in which the heat source, being a hot engine-cooling fluid, water, transfers heat to air flowing through the radiator (i.e. the heat transfer medium).

Description

Shell and tube heat exchanger :- The shell & tube heat exchanger is the commonest type. It is the most common type of heat exchanger in oil refineries and other large chemical processes, and is suited for higher-pressure applications. As its name implies, this type of heat exchanger consists of a shell (a large pressure vessel) with a bundle of tubes inside it. One fluid runs through the tubes, and another fluid flows over the tubes (through the shell) to transfer heat between the two fluids. The set of tubes is called a tube bundle, and may be composed by several types of tubes: plain, longitudinally finned, and other types.

Plate heat exchanger :- All plate heat exchangers look similar on the outside. The difference lies on the inside, in the details of the plate design and the sealing technologies used. Hence, when evaluating a plate heat exchanger, it is very important not only to explore the details of the product being supplied, but also to analyze the level of research and development carried out by the manufacturer and the post-commissioning service and spare parts availability.

Gas Fired Hot Air Generator

Airotherm is a combination of shell-in-shell and tube-in-shell type hot air generator. It has four concentric shells. The furnace shell has a blind end where the flue gases are reversed over the flame itself forming the 1st and 2nd pass. The 3rd pass is situated between the 2nd &3rd shell from where the flue gases, led via a duct, to the tube-in-shell type heat exchanger. The 4th & 5th pass are through tubes of the tube-in-shell heat exchanger.

The burner assnmbly is bolted on a removable inner cover plate. The combustion air is led to an air register which is formed by the annular space of the inner cover and the outer cover. The air going for combustion is thus preheated.

The fresh air has four passes to absorb heat from the flue gases. The 1st pass of the cold air enters around the 5th pass of the flue gases. Likewise all the subsequent passes of the air and flue are in counter current mode enabling maximum heat transfer. The final 4th pass of the fresh airwhich is at the last leg of the heat transfer path wraps around the furnace in circular path absorbing the heat attaining the required temperature for the process.

The max temp for this model of heater is 300 The design of the heater is made simple and operator friendly.
